DOOSAN PUMA 2100 VS. CMZ TA
TECHNICAL SPECIFICATION COMPARISON
-
Puma 2100
CNC single turret, slant bed lathe with 65 mm bar capacity - Prismatic guides
- Standard belt driven spindle
- Belt-driven tool
- Weight = 6500 kg
- Maximum turning diameter = 406 mm
- X travel = 260 mm
- Y travel= 105 mm
- Z travel = 590 /830 mm
- Spindle - 358 Nm and 22 kW
- Sub-Spindle - 134 Nm and 15 kW
- Turret - 5000 rpm and 5.5 kW
-
CMZ TA 20
CNC single turret lathe with 66 mm bar capacity - Prismatic guides
- Built-in motor in the standard spindle
- Built-in motor for the live tool drive
- Weight = 7100 kg
- Maximum turning diameter = 450 mm
- X travel = 310 mm
- Y travel = +70 /-50 mm
- Z travel options = 400/640/1100
- Spindle - 366 Nm and 22 kW
- Sub-Spindle - 292 Nm and 14 kW
- Turret - 12,000 rpm and 11.3 kW
DOOSAN PUMA 2100 VS. CMZ TA
DO YOU WANT TO ACCESS THE FULL TECHNICAL DETAILS?
HIGH PERFORMANCE CNC MACHINE FOR SALE WITH PRISMATIC BED
COMPARE DOOSAN PUMA 2100 WITH CMZ TA
DISCOVER THE MAIN DIFFERENCES BETWEEN THESE LATHES
The Puma 2100 and CMZ TA 20 machines have been designed for the same type of part, they can be described as competitors. Nevertheless, analysis of their features shows there are technical differences.
The X, Y, Z travels in the CMZ TA 20 are longer than in the Puma 2100 , and can therefore handle larger parts.
The CMZ TA 20 spindle is more powerful than the Puma 2100 spindle, in terms of power and torque rating. It also has a higher milling capacity: the live tool drive produces 12,000 rpm and 11.3 kW compared to the 5000 rpm and 5.5 kW of the Puma 2100.
